Loadable Material Sizes
|
Model name |
Width |
Length |
GR-640 |
156 to 1,802 mm |
Roll material: no restriction Flat material: 200 mm or more |
GR-540 |
156 to 1,548 mm |
|
GR-420 |
156 to 1,224 mm |
CAUTION
Never load media that weighs over 40 kg (88.19 lb.).
The machine may fail to withstand the weight, causing the machine to tip over or the material to fall.
A) Cuttable material thickness
Material thickness of 1 mm or less*
B) Material thickness (including carrier paper)
2 mm or less*
* Conditions differ according to the type of blade.
Refer to "General Guide Regarding Cutting Conditions."Cuttable Area
|
Model name |
Maximum cutting area |
GR-640 |
Width: 1,651 mm (65 inches)(*) |
Length: 24,998 mm |
|
GR-540 |
Width: 1,397 mm (55 inches)(*) |
Length: 24,998 mm |
|
GR-420 |
Width: 1,075 mm (42.3 inches)(*) |
Length: 24,998 mm |
* The maximum width can be extended by up to 20 mm depending on settings. However, this may cause the pinch roller to leave marks on the products. Exercise caution. For instructions on how to extend the cutting area, refer to "Extending the Cutting Area <EXTEND>."
Explanation of Cutting Area
The cutting area along the material's horizontal plane (the direction in which the cutting carriage moves) is determined by the position of the pinch rollers. The cutting area spans the length between the two rollers, minus approximately 1 mm on each side.
|
Type of specified material
|
Cutting area
|
[ROLL] or [EDGE] |
<Width>: Distance between the two pinch rollers minus approximately 1 mm on each side <Length>: 24,998 mm |
[PIECE] |
<Width>: Distance between the two pinch rollers minus approximately 1 mm on each side
<Length>: Detected length(*) |
*: If the detected length is 1,600 mm or more, the machine determines the material to be [ROLL], and the length of the cutting area is set to 24,998 mm.
However, the display does not show the length.
|
*: For the range for assured accuracy, refer to the specifications. |
: Cutting area
: Pinch roller
